Stainless Steel 316 Flanges Shipped To Iran

On September 30, 2025, we received an inquiry from an Iranian customer for 316 flanges. The customer has high requirements for the dimensional accuracy and quality of TP316 flanges.

316 stainless steel flanges not only possess excellent resistance to atmospheric corrosion and high-temperature strength, but also have good machinability. This ensures that the flanges maintain long service life and reliable sealing performance under harsh conditions such as chemical, marine, food processing, power, and oil and gas industries, effectively protecting system safety and reducing maintenance costs.

图

Stainless Steel 316 Flanges Shipped To Iran

Regarding manufacturing standards, our 316 stainless steel flanges strictly adhere to specifications such as Chinese national standard GB/T 9112~9124-2010 or American standard ASME B16.5. We offer a variety of structural types, such as weld neck, slip-on flanges, and blind flanges, and a complete range of pressure ratings to ensure a perfect match with your existing piping system.

Through sophisticated manufacturing processes and strict quality control, our flange products have a tensile strength of not less than 620 MPa and a yield strength of not less than 310 MPa, maintaining excellent mechanical properties even under high pressure and high temperature conditions.

Type: Welneck Flange, Material standard: ASTM A182, Material grade: F316 Dimensional standard: ASME B16.5, End face: Raised face (RF) Schedule pressure class: 150#, Size: 2 inch, Sch 40S	Type: Welneck Flange, Material standard: ASTM A182, Material grade: F316 Dimensional standard: ASME B16.5, End face: Raised face (RF) Schedule pressure class: 150#, Size: 3 inch, Sch 40S
Type: Welneck Flange, Material standard: ASTM A182, Material grade: F316 Dimensional standard: ASME B16.5, End face: Raised face (RF) Schedule pressure class: 150#, Size: 4 inch, Sch 40S	Type: Welneck Flange, Material standard: ASTM A182, Material grade: F316 Dimensional standard: ASME B16.5, End face: Raised face (RF) Schedule pressure class: 150#, Size: 6 inch, Sch 10S
Type: Welneck Flange, Material standard: ASTM A182, Material grade: F316 Dimensional standard: ASME B16.5, End face: Raised face (RF) Schedule pressure class: 150#, Size: 8 inch, Sch 10S	Type: Welneck Flange, Material standard: ASTM A182, Material grade: F316 Dimensional standard: ASME B16.5, End face: Raised face (RF) Schedule pressure class: 150#, Size: 10 inch, Sch 10S
Type: Welneck Flange, Material standard: ASTM A182, Material grade: F316 Dimensional standard: ASME B16.5, End face: Raised face (RF) Schedule pressure class: 150#, Size: 12 inch, Sch 10S	Type: Blind Flange, Material standard: ASTM A182, Material grade: F316 Dimensional standard: ASME B16.5, End face: Raised face (RF)Schedule pressure class: 150#, Size: 2 inch
Type: Blind Flange, Material standard: ASTM A182, Material grade: F316 Dimensional standard: ASME B16.5, End face: Raised face (RF) Schedule pressure class: 150#, Size: 3 inch	Type: Blind Flange, Material standard: ASTM A182, Material grade: F316 Dimensional standard: ASME B16.5, End face: Raised face (RF) Schedule pressure class: 150#, Size: 4 inch

Excellent Resistance to Chloride Corrosion

316 stainless steel is a molybdenum-containing austenitic stainless steel. The addition of molybdenum significantly improves the alloy's resistance to pitting and crevice corrosion. In coastal and marine environments, 316 flanges offer a longer service life.

Stability and Strength under High Temperature and Pressure

316 stainless steel maintains excellent tensile and yield strength at high temperatures and exhibits good creep resistance. For high-temperature and high-pressure piping systems in oil refining, steam systems, heat exchangers, and the power industry, 316 flanges possess reliable mechanical properties to withstand continuous stress and thermal cycling.

Excellent Resistance to Acid and Chemical Corrosion

316 steel exhibits excellent resistance to a variety of corrosive chemical media, especially reducing acids. In the chemical, pharmaceutical, and pulp industries, piping systems frequently transport various corrosive fluids. 316 flanges resist the corrosive effects of these chemicals, maintaining the integrity of the flange sealing surface and body.

Excellent Weldability and Machinability

Although 316 is slightly more difficult to machine than 304, as an austenitic stainless steel, it still possesses excellent weldability and machinability. Whether manufacturing complex flange shapes or performing on-site welding connections with 316 flanges, 316 flanges provide reliable weld quality.

Hygiene Standards

In industries with extremely high hygiene requirements, such as food processing, beverage, pharmaceuticals, and biotechnology, 316 stainless steel does not release harmful substances or metal ions into the processing medium. Its surface is easily polished to a smooth, non-porous finish, facilitating thorough cleaning and disinfection, and effectively preventing microbial growth.

Stainless Steel 316 Flanges Shipped To Iran

JN Iran 316 Stainless Steel Flange Program

Why Choose JN 316 Stainless Steel Flanges?
